Description
Standard Equipment
4 Filling connections of your choice of 2216, 3000, 4500 – 6000 psi Connections
4 filling hoses of 1.2 m (3′) in length
Pressure maintenance valve
Interstage control gauges
Double PED certified Hyperfilter filter system
Cabin internal temperature with automatic switch-off
Automatic condensate drain
Automatic direction of rotation control
Electronic pressure switch with automatic shutdown
Oil level control with automatic shutdown
Oil pump
Automatic condensate drain with conveyor system in the tank
Frame color Black RAL 9005
Technical data
Type of gas
Breathing air – Nitrox 40% max O2 – Helium – Nitrogen
Intake pressure
Atmospheric Pressure
Nominal pressure
2216 PSI / 4500 PSI / 6000 PSI
Working pressure
2216 PSI / 4500 PSI / 6000 PSI
Max working pressure
6000 PSI
Permissible ambient temperature range
-10° C (10 F) ÷ +40° C (104 F)
Permissible altitude
0 ÷ 1.500 m SLM ( 5,000′)
Max permissible tilt
15°
Design
Cabinet insonorizzato
Operating voltage, standard
400 V; 50 Hz
Other operating voltage
On three-phase electric motor at 60Hz the power (kW / Hp) increases by 20%.
230 V 50 hz / 440 V 60 hz / 230 V 60 hz
Oil
Synthetic Coltri Oil ST 755
Oil change interval
Every year / 1,000 h
Frame
Steel thickness 1.5 mm – color RAL 9005 – Powder coating – scratch-resistant
