Description
Standard Equipment
2 Cylinder connections to choose from 2216, 4500 or 6000 PSI
2 whips 1.2m (3′) long
Pressure maintenance valve
Interstage control gauges
Double PED certified Hyperfilter filter system
Cabin internal temperature with automatic switch-off
Automatic condensate drain
Automatic direction of rotation control
Electronic pressure switch with automatic shutdown
Oil level control with automatic shutdown
Oil pump with filter and pressure gauge
Automatic condensate drain with conveyor system in the tank
Frame color Blue RAL 5002
Technical data
Type of gas
Breathing air
Intake pressure
Atmospheric
Nominal pressure
2216, 4500 or 6000 PSI
Working pressure
2216, 4500 or 6000
Max working pressure
232 bar (elettrico monofase) – 420 bar (elettrico trifase)
Permissible Ambient Temperature range
(14 F) -10° C ÷ (104 F) +40° C
Permissible altitude
0 ÷ 1.500 m SLM
Max permissible tilt
15°
Design
Cabinet insonorizzato con fonoassorbente
Operating voltage, standard
400 V; 50 Hz
Other operating voltage
On three-phase electric motor at 60Hz the power (kW / Hp) increases by 20%.
230 V, 50 Hz / 440 V, 60 Hz / 230 V, 60 Hz
Oil
Synthetic Coltri Oil ST 755
Oil change interval
1 year / 1,000 h
Frame
Steel thickness 1.5 mm – color Blue RAL 5002 – Powder coating – scratch-resistant
Noise
LpA 63 dB
